Manor Pergola Kit

1.00 LBS
Calculated at Checkout

Product Description

Step into an outdoor living space that you can be proud of with our Manor Pergola Kit. Base package includes top runners at 4" on center, providing ample shade against the hot sun.

How measured and quoted: displayed sizes are to the outside face of the posts. For example, a 10'-4" x 12'-4" size measures 10'-4" x 12'-4" to the outside face of the posts. The rafters and runners extend past the post edge 16" on all sides. This means a 10'-4" x 12'-4" size has an overall roof span and coverage area of 13' x 15'.

Width x Length: Width (W) = the span of the 2x6 rafters. Length (L) = the span of the 2x10 main beams.

Number of posts: beams can span 16ft from the outside face of one post to the outside face of the other. Therefore the largest size that has only four posts is a 16' x 16'. Spans longer than 16ft require a middle post.

Base Package includes:

  • 100% southern treated pine#1 grade, air dried
  • Shop-applied stain and sealant in a color of your choice (six colors below), extends the lifespan of your pergola and enhances its beauty
  • 2x2 top runners at 4" on center, providing lots of shade
  • 2x6 rafters at 18" on center, notched for stability and craftsmanship to fit over 2x10 beams
  • (4) 2x10 beams, two on each side of the pergola
  • 6x6 posts 8ft tall
  • Post base trim 10 1/2" square for 6x6  posts
  • Bottom of main 2x10 beams is 7'-3" if you select standard 8ft tall posts
  • All hardware necessary to assemble
  • Simpson Strongtie RPBZ post brackets (two per post) and concrete lag bolts to fasten to your foundation (wood lags also available for deck mounting)
  • Triangular braces to lessen racking
  • Easy step-by-step assembly manual to guide you thru assembly
  • Shop drawings at the outset of each order (before fabrication of your kit) to confirm your understanding of all dimensions
  • On call service to answer any assembly questions
  • Ten year warranty

Assembly time: a 12x12 size can be assembled by two tradesman in four hours. Allow eight hours for a less handy homeowner. We include an easy-to-follow assembly manual with all kits. Check out the assembly manual here.

Shipping: shipping is free to all states except AZ, CA, ID, MT, NV, OR, UT, and WA for which a shipping charge of 5-8% applies.


  • 10ft tall or 12ft tall posts
  • 8x8 smooth posts
  • 8x8 recessed posts
  • 36" tall post base trim
  • Corner braces for taller post options
  • Six stain colors
  • Napa rafter tails or scroll cut tails
  • Post base trim is 12 1/2" square for 8x8 and recessed posts
